ArduinoInterpreter

A complete Arduino/C++ code interpreter system for browser and Node.js environments

ArduinoInterpreter is a production-ready parser and interpreter that transforms Arduino/C++ source code into executable command streams through a sophisticated multi-stage processing pipeline. It provides full Arduino language support with hardware simulation, making it perfect for educational tools, code validation, and Arduino development environments.

Whats Next?

The process of porting our JavaScript codebase to C++ is officially underway. This transition will enable us to compile for both WebAssembly (Wasm) and Arduino ESP32 binaries from a single source. Initial tests are very encouraging, revealing lower memory usage and a speed boost of up to 50%. More updates will follow, pending my ability to figure out how to pay for a Claude subscription.

Funding

We are urgently in need of funding for this project to continue the longer term goals ... We will be start a tradition funding campaign but for now we are asking for small amount donations to help keep paying for a minimal subscription to claude code ... $20 per month minimum or $100 per month maximum is what we need ... If you can help please click the button

πŸš€ Architecture Overview

ArduinoInterpreter uses a clean, modular architecture that processes Arduino code through four distinct stages:

Arduino Code β†’ Platform Context β†’ Preprocessor β†’ Parser β†’ AST β†’ Interpreter β†’ Command Stream
     ↓              ↓              ↓           ↓      ↓          ↓              ↓
  Raw C++      ESP32 Defines    Macro        Clean  Abstract   Hardware    Structured
  Source       Pin Mappings     Expansion    Code   Syntax     Simulation  Commands
  Code         Libraries        Conditionals        Tree       Events      for Parent App

Processing Pipeline

  1. Platform Emulation - Provides Arduino platform context (ESP32 Nano by default)
  2. Preprocessing - Handles macros, includes, and conditional compilation
  3. Parsing - Generates clean Abstract Syntax Tree from preprocessed code
  4. Interpretation - Executes AST with hardware simulation and command emission

πŸ—οΈ Core Modules

platform_emulation.js - Platform Context

  • Purpose: Provides Arduino platform-specific definitions and capabilities
  • Default Platform: ESP32 Nano (Arduino Nano ESP32)
  • Features: Pin mappings, hardware defines, library support, switchable platforms
  • Output: Platform context with defines like ESP32, WIFI_SUPPORT, BLUETOOTH_SUPPORT

preprocessor.js - Arduino Preprocessor

  • Purpose: Complete C++ preprocessing with Arduino-specific extensions
  • Input: Raw Arduino/C++ source code + platform context
  • Features:
    • Macro expansion (#define LED_COUNT 60, #define AREA(r) (3.14 * r * r))
    • Library activation from includes (#include <Adafruit_NeoPixel.h>)
    • Conditional compilation (#ifdef ESP32, #if defined(WIFI_SUPPORT))
    • Complete directive removal for clean parser input
  • Output: Clean C++ code ready for parsing + metadata (active libraries, macros)

parser.js - Arduino C++ Parser

  • Purpose: Lexical analysis and Abstract Syntax Tree generation
  • Input: Clean preprocessed C++ code (no preprocessor directives)
  • Features:
    • Complete Arduino/C++ language support
    • Enhanced error handling and recovery
    • Support for Arduino-specific constructs and libraries
    • Template support (std::vector<int>, ClassName<Type>)
    • Namespace support (std::vector, rtttl::isPlaying)
  • Output: Abstract Syntax Tree (AST) with clean structure

interpreter.js - AST Interpreter & Hardware Simulator

  • Purpose: Executes AST and simulates Arduino hardware behavior
  • Input: Abstract Syntax Tree + configuration options
  • Features:
    • Variable management and scope handling
    • Arduino function simulation (pinMode, digitalWrite, analogRead)
    • Hardware simulation (pins, timing, serial communication)
    • Library interface support (NeoPixel, Servo, Wire, SPI)
    • Request-response pattern for external data functions
    • Loop control and execution flow management
  • Output: Structured command stream for parent application integration

🎯 Command Stream Architecture

The interpreter generates a clean, structured command stream that parent applications can easily process:

// Example command stream output
{ type: 'PIN_MODE', pin: 13, mode: 'OUTPUT' }
{ type: 'DIGITAL_WRITE', pin: 13, value: 1 }
{ type: 'DELAY', duration: 1000 }
{ type: 'ANALOG_READ_REQUEST', pin: 'A0', requestId: 'req_001' }
{ type: 'SERIAL_PRINT', data: 'Hello World', newline: true }

Commands contain only primitive data types (no nested objects) for maximum compatibility with parent applications, embedded systems, and serialization protocols.

πŸ“Š Project Status

πŸ† Production Ready - 100% test coverage across all components

Component Version Test Suite Success Rate Tests
Parser v5.0.0 Arduino Examples 100% βœ… 79/79
Interpreter v6.3.0 Comprehensive Tests 100% βœ… 54/54
Preprocessor v1.2.0 NeoPixel Tests 100% βœ… 2/2
Platform Emulation v1.0.0 Total Coverage 100% βœ… 135/135

Test Coverage

  • Execution Success: 100% - All 135 test cases execute without errors
  • Semantic Accuracy: 100% - All outputs match expected Arduino behavior
  • Library Support: Complete - NeoPixel, Servo, Wire, SPI, EEPROM libraries
  • Language Features: Full C++ support including templates, namespaces, pointers

πŸš€ Quick Start

Node.js Usage

const { parse } = require('./parser.js');
const { ArduinoInterpreter } = require('./interpreter.js');
const { PlatformEmulation } = require('./platform_emulation.js');

// 1. Set up platform context (ESP32 Nano by default)
const platform = new PlatformEmulation('ESP32_NANO');

// 2. Parse Arduino code with preprocessing
const arduinoCode = `
#define LED_PIN 13
void setup() {
  pinMode(LED_PIN, OUTPUT);
}
void loop() {
  digitalWrite(LED_PIN, HIGH);
  delay(1000);
}`;

const ast = parse(arduinoCode, {
  enablePreprocessor: true,
  platformContext: platform
});

// 3. Create interpreter with hardware simulation
const interpreter = new ArduinoInterpreter(ast, {
  maxLoopIterations: 3,  // Prevent infinite loops in testing
  verbose: false
});

// 4. Handle command stream
interpreter.onCommand = (command) => {
  console.log('Arduino Command:', command);
  // Process commands in your application
};

// 5. Start execution
interpreter.start();

Browser Usage

<!DOCTYPE html>
<html>
<head>
    <script src="platform_emulation.js"></script>
    <script src="preprocessor.js"></script>
    <script src="parser.js"></script>
    <script src="interpreter.js"></script>
</head>
<body>
    <script>
        // All modules auto-export to window globals
        const platform = new PlatformEmulation('ESP32_NANO');
        const ast = parse(arduinoCode, {
            enablePreprocessor: true,
            platformContext: platform
        });
        const interpreter = new ArduinoInterpreter(ast);

        interpreter.onCommand = (command) => {
            // Handle Arduino commands in your web application
        };

        interpreter.start();
    </script>
</body>
</html>

πŸ§ͺ Testing & Development

Running Tests

# Interpreter Tests (full execution simulation)
node test_interpreter_examples.js    # Arduino examples (79 tests)
node test_interpreter_old_test.js    # Comprehensive cases (54 tests)
node test_interpreter_neopixel.js    # NeoPixel library tests (2 tests)

# Parser Tests (parsing validation only)
node test_parser_examples.js         # Fast parsing validation
node test_parser_old_test.js         # Advanced language features
node test_parser_neopixel.js         # Library parsing tests

# Semantic Accuracy Tests (behavior validation)
node test_semantic_accuracy_examples.js  # Validate command stream correctness
node test_semantic_accuracy.js           # Advanced semantic validation

Interactive Development

# Interactive interpreter testing (recommended)
open interpreter_playground.html

# Interactive parser testing
open parser_playground.html

πŸ”§ Advanced Features

Platform Switching

// Switch to Arduino Uno platform
const unoplatform = new PlatformEmulation('ARDUINO_UNO');
const ast = parse(code, { platformContext: unoPlatform });

Preprocessor Control

// Fine-tune preprocessing behavior
const ast = parse(code, {
  enablePreprocessor: true,
  platformContext: platform,
  verbose: true  // Show preprocessing details
});

Hardware Simulation Configuration

const interpreter = new ArduinoInterpreter(ast, {
  maxLoopIterations: 10,      // Control loop execution
  stepDelay: 0,               // Execution timing (0 = no delay)
  verbose: false,             // Suppress debug output
  debug: false                // Disable debugging features
});

// Handle external data requests (analogRead, digitalRead, etc.)
interpreter.responseHandler = (request) => {
  // Mock hardware responses
  const mockValue = request.type === 'analogRead' ?
    Math.floor(Math.random() * 1024) :
    Math.random() > 0.5 ? 1 : 0;

  setTimeout(() => {
    interpreter.handleResponse(request.id, mockValue);
  }, 10); // Simulate hardware delay
};

πŸ“š Supported Arduino Features

Language Constructs

  • Data Types: int, float, double, char, bool, String, byte, etc.
  • Control Structures: if/else, for, while, do-while, switch/case
  • Functions: Definitions, calls, parameters, overloading
  • Arrays: Single and multi-dimensional, dynamic allocation
  • Pointers: Basic pointer operations and arithmetic
  • Structs/Classes: Member functions, constructors, inheritance
  • Templates: Template instantiation and specialization
  • Namespaces: Qualified access (std::vector, namespace::member)

Arduino Libraries

  • Built-in: pinMode, digitalWrite, digitalRead, analogRead, analogWrite
  • Timing: delay, delayMicroseconds, millis, micros
  • Serial: Serial.print, Serial.println, Serial.available
  • Advanced Libraries: Adafruit_NeoPixel, Servo, Wire (I2C), SPI, EEPROM
  • Hardware: PWM, interrupts, timers, communication protocols

Preprocessor Features

  • Macros: Simple (#define LED_PIN 13) and function-like (#define MAX(a,b) ((a)>(b)?(a):(b)))
  • Includes: Library activation (#include <Adafruit_NeoPixel.h>)
  • Conditionals: #ifdef, #ifndef, #if defined(), #else, #endif
  • Platform Defines: ESP32, ARDUINO, WIFI_SUPPORT, BLUETOOTH_SUPPORT

πŸ”­ Other Option

The ArduinoInterpreter project is not a full Simulator for the Arduino ... The goal for this project is to be the "preprocessor, parser, and interpreter" part for a simulated Arduino environment (not provided). There are other projects that perform full "emulation" or full "simulation" of the Arduino environment ... most notably wokwi.com and Tinkercad ... the closet in scope to this project would be the ArduinoSimulator project that converts Arduino sketches to a portable C++ that then gets used by 'JSCPP' to simulate the Arduino environment within the browser (or nodejs) . While the projects have similar goals ... the complexity and inclusion of the JSCPP library into the ArduinoSimulator makes it unessarly bloated code ...

This project began as a 30-day experiment

This project began as a 30-day experiment using AI technologies to solve a previously unsuccessful programming challenge. The result is now available to the open source educational community under dual licensing (Source-Available License and AGPLv3), with commercial licensing available.

πŸ“œ Licensing

This project is dual-licensed under the sfranzyshen.com Source-Available License 1.0

and sfranzyshen.org with GNU AGPLv3.

  • You may use this software under the terms of the Source-Available License for non-production purposes (e.g., development, testing).
  • After the Change Date of 8/26/2030, the software will automatically be governed by the AGPLv3.
  • If you wish to use this software in a production environment before the Change Date, you must obtain a commercial license. Please contact us at [sfranzyshen@hotmail.com] for more details.
